LBH04-S8-O160 LCE 8W 12W 15W 18W 20W 22W | LED BULKHEAD

LBH04-S8-O160 LCE,LBH04-S12-O160 LCE,LBH04-S15-O200 LCE,LBH04-S18-O200 LCE,LBH04-S20-O230 LCE,LBH04-S22-O230 LCE

To print

Input: AC220-240V, 50/60Hz

Installation: 15cm 2*0.4 square PVC outer line (tail dipping tin)

LED type: SMD2835

Driver: LIC driver

Material: PP flame retardant plastic + PP diffusion flame retardant lampshade

Life time: 15000h

CCT

TECHNICAL CHARACTERISTICS

4F7EBF94145C464C86FD14170F691210

Code	Input	Power	Lumen	PF	C.R.I	IP Grade
Oval LED bulkhead light
LBH04-S8-O160 LCE	220-240V	8W	720lm	0.5	80	54
LBH04-S12-O160 LCE	220-240V	12W	1080lm	0.5	80	54
LBH04-S15-O200 LCE	220-240V	15W	1350lm	0.5	80	54
LBH04-S18-O200 LCE	220-240V	18W	1620lm	0.5	80	54
LBH04-S20-O230 LCE	220-240V	20W	1800lm	0.5	80	54

Code	Input	Power	Lumen	C.R.I	C.C.T.	IP Grade
Oval LED bulkhead light
LBH04-S22-O230 LCE	220-240V	22W	1980lm	0.5	80	54

Code	Input	Power	Lumen	C.R.I	C.C.T.	IP Grade
Oval LED bulkhead light
LBH04-S8-R140 LCE	220-240V	8W	720lm	0.5	80	54
LBH04-S12-R140 LCE	220-240V	12W	1080lm	0.5	80	54
LBH04-S15-R175 LCE	220-240V	15W	1350lm	0.5	80	54
LBH04-S18-R175 LCE	220-240V	18W	1620lm	0.5	80	54
LBH04-S20-R208 LCE	220-240V	20W	1800lm	0.5	80	54

Code	Input	Power	Lumen	C.R.I	C.C.T.	IP Grade
Oval LED bulkhead light
LBH04-S22-R208 LCE	220-240V	22W	1980lm	0.5	80	54
