LBH-S8G-OV157-IC 8W 12W 15W 18W 20W | LED BULKHEAD

LBH-S8G-OV157-IC,LBH-S12G-OV157-IC,LBH-S15G-OV192-IC,LBH-S18G-OV192-IC,LBH-S20G-OV192-IC

To print

Input: AC165-265V, 50Hz

Beam Angle: 120°

Driver: IC driver

Material: PP base+PP cover

Life time: 25000h

Inquiry

TECHNICAL CHARACTERISTICS

4F7EBF94145C464C86FD14170F691210

Code	Power	Lumen	C.R.I	C.C.T.	Size
Oval LED bulkhead light 165-265V,IP54
LBH-S8G-OV157-IC	8W	640lm	80	3000-6500K	L157W80H45mm
LBH-S12G-OV157-IC	12W	960lm	80	3000-6500K	L157W80H45mm
LBH-S15G-OV192-IC	15W	1200lm	80	3000-6500K	L192W90H45mm
LBH-S18G-OV192-IC	18W	1440lm	80	3000-6500K	L192W90H45mm
LBH-S20G-OV192-IC	20W	1600lm	80	3000-6500K	L192W90H45mm

Code	Power	Lumen	C.R.I	C.C.T.	Size
Oval LED bulkhead light 165-265V,IP54
LBH-S8G-R140-IC	8W	640lm	80	3000-6500K	Φ140*H45mm
LBH-S12G-R140-IC	12W	960lm	80	3000-6500K	Φ140*H45mm
LBH-S15G-R175-IC	15W	1200lm	80	3000-6500K	Φ175*H45mm
LBH-S18G-R175-IC	18W	1440lm	80	3000-6500K	Φ175*H45mm
LBH-S20G-R175-IC	20W	1600lm	80	3000-6500K	Φ175*H45mm
