LED T5 FIXTURE 4-16W 30-120CM PC_LED LINEAR LIGHT_PRODUCTS

Basic information:
Plastic 4W, 8W, 12W, 16W, 30cm, 60cm, 90cm, 120cm LED cabinet T5 fixture
Base: Connector and wires
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PC shell, PC diffuser
Application: Cabinet, furniture, Shops shelf, restaurants, hotels, Book shelf,etc.

top mid pic.png

Inquiry

TECHNICAL CHARACTERISTICS

Safety according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015

mid pic 693x166.png

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Size(LWH)	Switch	Dim or Non-dim
T5 LED Fixture 30CM
LT50304PCB01	100-240V	4 W	0.5	360lm	80	3000K	3042236mm	Option	Option
LT50304PCB01	100-240V	4 W	0.5	360lm	80	4000K	3042236mm	Option	Option
LT50304PCB01	100-240V	4 W	0.5	360lm	80	6500K	3042236mm	Option	Option
LT50304PCB01	100-240V	4 W	0.5	360lm	80	8000K	3042236mm	Option	Option

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Size(LWH)	Switch	Dim or Non-dim
T5 LED Fixture 60CM
LT50608PCB01	100-240V	8 W	0.5	720lm	80	3000K	5742236mm	Option	Option
LT50608PCB01	100-240V	8 W	0.5	720lm	80	4000K	5742236mm	Option	Option
LT50608PCB01	100-240V	8 W	0.5	720lm	80	6500K	5742236mm	Option	Option
LT50608PCB01	100-240V	8 W	0.5	720lm	80	8000K	5742236mm	Option	Option

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Size(LWH)	Switch	Dim or Non-dim
T5 LED Fixture 90CM
LT50912PCB01	100-240V	12 W	0.5	1080lm	80	3000K	8742236mm	Option	Option
LT50912PCB01	100-240V	12 W	0.5	1080lm	80	4000K	8742236mm	Option	Option
LT50912PCB01	100-240V	12 W	0.5	1080lm	80	6500K	8742236mm	Option	Option
LT50912PCB01	100-240V	12 W	0.5	1080lm	80	8000K	8742236mm	Option	Option

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Size(LWH)	Switch	Dim or Non-dim
T5 LED Fixture 120CM
LT51216PCB01	100-240V	16 W	0.5	1440lm	80	3000K	11792236mm	Option	Option
LT51216PCB01	100-240V	16 W	0.5	1440lm	80	4000K	11792236mm	Option	Option
LT51216PCB01	100-240V	16 W	0.5	1440lm	80	6500K	11792236mm	Option	Option
LT51216PCB01	100-240V	16 W	0.5	1440lm	80	8000K	11792236mm	Option	Option

LED T5 FIXTURE 4-16W 30-120CM PC | LED LINEAR LIGHT

LT50304,LT50608,LT50912,LT51216
