LDN-L1 | LED POWER SUPPLY

LDNL-CVXY

To print

BASIC INFORMATION:
Line LED Power Supply, Constant DC12/24V 60W, 100W, 150W, 200W, 250W, 300W, IP20
Driver Type: Constant voltage IC
Housing material: Aluminium (6063)
Installation: Wires
Application: LED cabinet light, LED strip light, etc.

Safety Standard:
EN613471,EN61347-2-13
EMI: EN55015
EMS: EN6 1000-3-2.: EN61000-3-3; EN61547
EMF: EN62493-2010
ERP: EN1194-2012


Inquiry

TECHNICAL CHARACTERISTICS

CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 60W Line Type
LDNL-CV1260170-264VACDC12V,5A Max0-60W≥85%160*40*33IP20Not
LDNL-CV2460170-264VACDC24V,2.5A Max0-60W≥85%160*40*33IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 100W Line Type
LDNL-CV12100170-264VACDC12V,8.3A Max0-100W≥85%188*46*36IP20Not
LDNL-CV24100170-264VACDC24V,4.16A Max0-100W≥85%188*46*36IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 120W Line Type
LDNL-CV12120170-264VACDC12V,10A Max0-120W≥85%188*46*36IP20Not
LDNL-CV24120170-264VACDC24V,6A Max0-120W≥85%188*46*36IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
IP20 LED Driver 150W Line Type
LDNL-CV12150170-264VACDC12V,12.5A Max0-150W≥85%200*58*38IP20Not
LDNL-CV24150170-264VACDC24V,6.25A Max0-150W≥85%200*58*38IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 200W Line Type
LDNL-CV12200170-264VACDC12V,16.7A Max0-200W≥85%224*71*40IP20Not
LDNL-CV24200170-264VACDC24V,8.3A Max0-200W≥85%224*71*40IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 250W Line Type
LDNL-CV12250170-264VACDC12V,20.8A Max0-250W≥85%2224*71*40IP20Not
LDNL-CV24250170-264VACDC24V,10.4A Max0-250W≥85%2224*71*40IP20Not
CodePowerInputOutputλ(L*W*H/mm)IP GradeDim
LED Driver 300W Line Type
LDNL-CV12300170-264VACDC12V,30A Max0-300W≥85%2224*71*40IP20Not
LDNL-CV24300170-264VACDC24V,15A Max0-300W≥85%2224*71*40IP20Not
