PM IP44 | LED POWER SUPPLY

LDN-CVXYPM

BASIC INFORMATION:
IP44 LED power supply, Constant voltage Slim thin DC12V, 24V, 12W, 20W, 50W, 75W
Driver Type: Constant voltage IC
Housing material: PC(V0)
Installation: Wires
Application: LED cabinet light, LED strip light, etc.

Safety standard:
EN613471,EN61347-2-13
EMI: EN55015
EMS: EN6 1000-3-2.: EN61000-3-3; EN61547
EMF: EN62493-2010
ERP: EN1194-2012

Inquiry

TECHNICAL CHARACTERISTICS

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
12W IP44 CV 12/24V Line type LED Transformer
LDN-CV1212PM	12W	220-240V	DC12V,1A Max	≥84%	1325212	IP44	Non-dim
LDN-CV2412PM	12W	220-240V	DC24V,0.5A Max	≥84%	1325212	IP44	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
20W IP44 CV 12/24V Line type LED Transformer
LDN-CV1220PM	20W	220-240V	DC12V,1.66A Max	≥78%	1304217	IP44	Non-dim
LDN-CV2420PM	20W	220-240V	DC24V,0.83A Max	≥78%	1304217	IP44	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
50W IP44 CV 12/24V Line type LED Transformer
LDN-CV1250PM	50W	220-240V	DC12V,4.16A Max	≥86%	1585118	IP44	Non-dim
LDN-CV2450PM	50W	220-240V	DC24V,2.08A Max	≥86%	1585118	IP44	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
75W IP44 CV 12/24V Line type LED Transformer
LDN-CV1275PM	75W	220-240V	DC12V,6.25A Max	≥86%	1585818	IP44	Non-dim
LDN-CV2475PM	75W	220-240V	DC24V,3.12A Max	≥86%	1585818	IP44	Non-dim

PM IP44 | LED POWER SUPPLY

LDN-CVXYPM
