LPL01-18-RR225 ICC | LED PANEL LIGHT

LPL01-18-RR225 ICC,LPL01-24-RR300 ICC,LPL01-30-RR400 ICC...

BASIC INFORMATION:
Side-emitting LED panel light,18W 24W 30W 40W 50W,IEC|EN standard quality,Slim design and injection workmanship,High light efficiency 90lm/W
Installation: Side light emitting
Driver: Independent IC driver
Housing: ABS housing, PS diffuser
Application: Indoor lighting, household,etc

CCT

Inquiry

TECHNICAL CHARACTERISTICS

Code	Input	Power	DF	Lumen	C.R.I	Size
LED panel light, 50/60Hz,SDCM<6
LPL01-18-RR225 ICC	185-265V	18W	0.9	1450lm	82	Φ230*H25mm
LPL01-24-RR300 ICC	185-265V	24W	0.9	1920lm	82	Φ300*H25mm
LPL01-30-RR400 ICC	185-265V	30W	0.9	2550lm	82	Φ400*H25mm
LPL01-40-RR500 ICC	185-265V	40W	0.9	3200lm	82	Φ500*H25mm
LPL01-50-RR600 ICC	185-265V	50W	0.9	4000lm	82	Φ600*H25mm
