BACKLIT 300x1200 | LED PANEL LIGHT

LBPL-60120

BASIC INFORMATION:
Backlit LED panel light office light
LED: SMD2835
Driver: External driver
Housing: Irson, PS
Application: Office
class II luminaries certi icon

eel 180x180

Inquiry

TECHNICAL CHARACTERISTICS

EMC Directive 2014/30/EU(EMC)：

EN 55015: 2013,
EN 61547: 2009,
EN 61000-3-2:2014
EN 61000-3-3:2013
Safety Directive 2014/35/EU(LVD)：
EN 62560: 2012,
EN 62471: 2008,
EN 62473 :2015
ERP Directive: (EU) 2019/2020
EEL (EU) 2019/2015

middle size 1195x295 chart 360x180 ld 180x180

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
Backlit LED PANEL 30x120cm 36W
LBPL-30120-36	220-240V	36 W	0.9	3600lm	81	3000K	Normal
LBPL-30120-36	220-240V	36 W	0.9	3600lm	81	4000K	Normal
LBPL-30120-36	220-240V	36 W	0.9	3600lm	81	6500K	Normal

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
Backlit LED PANEL 30x120cm 40W
LBPL-30120-40	220-240V	40 W	0.9	4000lm	81	3000K	Normal
LBPL-30120-40	220-240V	40 W	0.9	4000lm	81	4000K	Normal
LBPL-30120-40	220-240V	40 W	0.9	4000lm	81	6500K	Normal

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
Backlit LED PANEL 30x120cm 48W
LBPL-30120-48	220-240V	48 W	0.9	4800lm	81	3000K	Normal
LBPL-30120-48	220-240V	48 W	0.9	4800lm	81	4000K	Normal
LBPL-30120-48	220-240V	48 W	0.9	4800lm	81	6500K	Normal

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
Backlit LED PANEL 30x120cm 80W
LBPL-30120-80	220-240V	80 W	0.9	7200lm	81	3000K	Normal
LBPL-30120-80	220-240V	80 W	0.9	7200lm	81	4000K	Normal
LBPL-30120-80	220-240V	80 W	0.9	7200lm	81	6500K	Normal
