LCL07-S12-R220 | LED CEILING LIGHT

LCL07-S12-R220,LCL07-S18-R300,LCL07-S36-R370,LCL07-S46-R370-CCT...

To print

BASIC INFORMATION:
LED ceiling light 12W 18W 36W 46W 64W 68W

LED: 12PCS SMD2835

Driver: Non-isolated drive

Housing: Iron + PP material

CCT

Inquiry

TECHNICAL CHARACTERISTICS

Code	Input	Powe	Lumen	C.R.I	C.C.T.	Size
LED ceiling light
LCL07-S12-R220	185-265V	12W	960lm	80	6500K	Φ200*H55mm
LCL07-S18-R300	185-265V	18W	1440lm	80	6500K	Φ300*H55mm
LCL07-S36-R370	185-265V	36W	2880lm	80	6500K	Φ370*H55mm
LCL07-S46-R370-CCT	185-265V	46W	3680lm	80	6500K	Φ370*H55mm
LCL07-S64-R460	185-265V	64W	5120lm	80	6500K	Φ460*H65mm

Code	Input	Powe	Lumen	C.R.I	C.C.T.	Size
LED ceiling light
LCL07-S68-R460-CCT	185-265V	68W	5120lm	80	6500K	Φ460*H65mm
LCL07-S64-S450	185-265V	64W	5120lm	80	6500K	L450W450H65mm
LCL07-S68-S450-CCT	185-265V	68W	5120lm	80	6500K	L450W450H65mm
