LED MR16 5W 6W 7W 38°60°120° | MR16

HX-S5F-MR16 LIC120D,HX-S5F-MR16 LIC60D,HX-S5F-MR16 LIC38D...

Power: 5W 6W 7W
Material: PLA+Alum body, PC diffuser
LED: Gold-wired with Copper stent
Driver: DOB LIC/IC driver
Base: GU5.3
Beam angle: 38°,60°,120°

DIM

Inquiry

TECHNICAL CHARACTERISTICS

Safety according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015

Code	Input	Power	PF	Total Lumen	C.R.I	Angle
LED MR16 50/60Hz,5W,6W,7W
HX-S5F-MR16 LIC120D	220-240V	5W	0.5	425lm	80	120°
HX-S6F-MR16 LIC120D	220-240V	6W	0.5	510lm	80	120°
HX-S7F-MR16 LIC120D	220-240V	6W	0.5	600lm	80	120°

Code	Input	Power	PF	Total Lumen	C.R.I	Angle
LED MR16 50/60Hz,5W,6W
HX-S5F-MR16 LIC38D	220-240V	5W	0.5	425lm	80	38°
HX-S5F-MR16 LIC60D	220-240V	5W	0.5	425lm	80	60°
HX-S6F-MR16 LIC38D	220-240V	6W	0.5	510lm	80	38°
HX-S6F-MR16 LIC60D	220-240V	6W	0.5	510lm	80	60°

Code	Input	Power	PF	Total Lumen	C.R.I	Angle
LED MR16 50/60Hz,7W
HX-S7F-MR16 LIC38D	220-240V	7W	0.5	600lm	80	38°
HX-S7F-MR16 LIC60D	220-240V	7W	0.5	600lm	80	60°
