IP20 Push-in LED ceiling light_LED CEILING LIGHT_PRODUCTS

BASIC INFORMATION:
Lamp power: 10W 12W 16W 28W 48W
Installation: Push-in installation
Connection: Terminal block backside
LED board: OSP Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PP shell
Application: Home, Desk, Shops, restaurants, hotels, coffee bar,etc.

eel E grade 180x180

Inquiry

TECHNICAL CHARACTERISTICS

EMC Directive 2014/30/EU(EMC)：
EN 55015: 2013
EN 61547: 2009
EN 61000-3-2:2014
EN 61000-3-3:2013
Safety Directive 2014/35/EU(LVD)：
EN 62560: 2012
EN 62471: 2008
EN 62473 :2015
ERP Directive: (EU) 2019/2020
EEL (EU) 2019/2015

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Control Mode
Push-in LED ceiling light
LCL-S10-230 EDN	185-265V	10 W	0.5	800LM	80	3000K	IP20	Non-dim
LCL-S10-230 EDN	185-265V	10 W	0.5	800LM	80	4000K	IP20	Non-dim
LCL-S10-230 EDN	185-265V	10 W	0.5	800LM	80	6500K	IP20	Non-dim

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Control Mode
Push-in LED ceiling light
LCL-S12-230 EDN	185-265V	12 W	0.5	960LM	80	3000K	IP20	Non-dim
LCL-S12-230 EDN	185-265V	12 W	0.5	960LM	80	4000K	IP20	Non-dim
LCL-S12-230 EDN	185-265V	12 W	0.5	960LM	80	6500K	IP20	Non-dim

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Control Mode
Push-in LED ceiling light
LCL-S16-270 EDN	185-265V	16 W	0.5	1280LM	80	3000K	IP20	Non-dim
LCL-S16-270 EDN	185-265V	16 W	0.5	1280LM	80	4000K	IP20	Non-dim
LCL-S16-270 EDN	185-265V	16 W	0.5	1280LM	80	6500K	IP20	Non-dim

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Control Mode
Push-in LED ceiling light
LCL-S28-370 EDN	185-265V	28 W	0.5	2240LM	80	3000K	IP20	Non-dim
LCL-S28-370 EDN	185-265V	28 W	0.5	2240LM	80	4000K	IP20	Non-dim
LCL-S28-370 EDN	185-265V	28 W	0.5	2240LM	80	6500K	IP20	Non-dim

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Control Mode
Push-in LED ceiling light
LCL-S48-470 EDN	185-265V	48 W	0.5	3840LM	80	3000K	IP20	Non-dim
LCL-S48-470 EDN	185-265V	48 W	0.5	3840LM	80	4000K	IP20	Non-dim
LCL-S48-470 EDN	185-265V	48 W	0.5	3840LM	80	6500K	IP20	Non-dim
